Workshop Environmental Sanitation Equipment

Effective workshop sanitation requires systems that can deliver consistent, repeatable cleaning performance at scale — with precise chemical dosing, reliable coverage of all surfaces, and meaningful reductions in water and chemical consumption compared to manual methods.

All equipment is constructed from SUS304 food-grade stainless steel and designed for the demanding conditions of industrial food processing workshops.

Product Range

Central Foam Cleaning Station

A fixed central hygiene management workstation integrating high-pressure water rinsing, foam cleaning, and disinfectant application in one installation. German-imported core valve technology, constant pressure control, and a 25m sanitary hose (auto-retract or manual reel) enable systematic, touch-free sanitation of all facility surfaces from a single point. Intelligent timer pre-sets standardize cleaning cycles across shifts. Reduces water consumption by 70% vs. conventional methods.

Workshop High-Pressure Foam Cleaning Machine

Versatile portable or fixed sanitation units for targeted surface cleaning across the workshop. Three-in-one functionality (high-pressure water / foam / disinfectant) with one-click switching. Four models cover different operational scales:

· HE-FS01 — Mobile standalone (80 Bar, built-in compressor, 2,500–3,000 m² foam coverage)

· HE-FS04 — Fixed station (30 Bar, precision proportional dosing, for large plants with centralized supply)

· HE-FS02/03 — Compact mobile pneumatic units for smaller workshops

All models achieve 80% water savings through flow-sensing auto-control. 25m food-grade hose on HE-FS01/FS04; 15m on HE-FS02/FS03.

Cleaning System Comparison

The Cleaning Workflow

Pre-Production Inspection

Verify equipment and surfaces are in acceptable condition before production begins.

During-Production Spot Cleaning

Use foam cleaning machine for targeted spot cleaning of contamination during production — without disrupting the full production line.

End-of-Shift Sanitation (Standard Procedure)

1. Pre-rinse — High-pressure water removes bulk organic matter from all surfaces

2. Foam application — Dense foam applied to all surfaces; contact time allows penetration of residues

3. Main rinse — High-pressure water removes foam and loosened contaminants

4. Disinfectant application — Sanitizing solution sprayed over all food-contact surfaces

5. Final rinse — Clean water flush for surfaces requiring zero chemical residue

Application Scenarios

Frequently Asked Questions

What is the difference between a central cleaning station and a foam cleaning machine?

The central cleaning station is a fixed installation designed for systematic, facility-wide hygiene management — it provides a permanent sanitation point with auto-retract hose management. The foam cleaning machine (HE-FS01/04) is a standalone or fixed unit designed for flexible, targeted cleaning in specific zones. Many facilities use both: the central station for end-of-shift full sanitation, and foam machines for during-production spot cleaning.

How does foam cleaning improve sanitation compared to water-only rinsing?

Foam clings to vertical and overhead surfaces, providing extended contact time that allows penetrating and loosening stubborn organic residues — fat, protein, and biofilm — that a simple water rinse cannot effectively remove. The result is more thorough cleaning with less water and chemical consumption.

What is the water saving mechanism?

Flow-sensing auto-control activates the pump only when the operator is actively cleaning, stopping flow when idle. This alone reduces water usage by 70–80% compared to conventional continuous-flow cleaning guns. Combined with precision chemical dosing, total sanitation costs are significantly reduced.

How do we standardize cleaning procedures across shifts?

The central cleaning station's intelligent timing system allows pre-programmed cleaning cycles with defined durations for each mode. This ensures every operator follows the same procedure regardless of shift, supporting consistent HACCP audit documentation.

Can the equipment handle overhead structures and ceiling areas?

Yes. The 25m hose on both the central cleaning station and HE-FS01/04 provides sufficient reach to address ceiling pipes, ventilation systems, and light fixtures that shorter-hose or manual equipment cannot effectively reach.
